Supmeter BST100-B11 - Speed Parameters (Sped)

41
6.3.6 Speed Parameters (SPEd)
No.
Sign
Parameter
Range
Default
Set
P400
-dot
Speed Decimal Point
0: o
1: o.o
2: o.oo
3: o.ooo
2
P401
rAng
Speed Range
0.100~5.000m/s
3.000
P402
-HI-
Speed Upper Limit
(0.0~100.0)% Speed Range
100.0%
P403
-Lo-
Speed Lower Limit
(0.0~100.0)% Speed Range
0.0%
P404
FILt
Speed Filter
1~200
10
P405
PuLS
Speed Source
0: Ext. Speed (Weighing by the external
speed)
1: Int. Speed1 (Weighing by the internal
speed)
2: Int. Speed2 (Connect a normally open
switch related to the running state of the
weighing belt between the terminals „SIN‟
and „VS-‟. Switch ON with Belt‟s
Running: Weighing by the internal speed;
Switch OFF with Belt‟s Stopping: Stop
weighing)
3: Int. Speed3 (Weighing by the internal
speed while the external speed pulse
inputting)
Note: If a DI signal is defined as „1:
Weighing‟, then only when this DI turns
on, the weighing process is allowed.
0
P406
InPL
Internal Speed
0.001~5.000m/s
0.500
P407
FrEH
Speed Pulse Frequency
Upper Limit
0.1~3.0kHz
If the frequency of speed pulse exceeds
this set value, the speed pulse will be
invalid.
1.0
