Supmeter BST100-B11 - Extra Control Parameters (Ctrl1)

39
6.3.4 Extra Control Parameters (CtrL1)
No.
Sign
Parameter
Range
Default
Set
P210
PIdL
PID Initial Current
Hold Time
0.0-999.9s
2.0
P211
InIC
PID Initial Current
0: Present (Present Current Value)
1: Fuzzy (Fuzzy Current Value)
2: Set [P219] (Set Value of [P219])
0
P212
FuZE
Fuzzy Equivalent
0.01~100.00 [t/h]/mA
([P107] Scale Unit = kg)
Flow Increment per Increasing 1mA
Adjusting Current.
2.50
0.01~100.00 [kg/h]/mA
([P107] Scale Unit = g)
P213
StdL
Start/Stop Delay
0.0~999.9s
Delay Time of Feeder Starting
Delay Time of Scale Stopping
0.0
P214
bCon
Batch Permission
0: OFF; 1: ON
0
P215
-bSt
Batch Loop Mode
0: Manual Mode; 1: Auto Mode
0
P216
-bdL
Batch Interval
0.0-9999.9s
60.0
P217
SEtb
Batch Weight Setpoint
0~99999999kg
([P107] Scale Unit = kg)
0
0~99999999g
([P107] Scale Unit = g)
P218
SEtP
Batch Preact Weight
0~[P217] kg
([P107] Scale Unit = kg)
Batch Preact Weight
0
0~[P217] g
([P107] Scale Unit = g)
P219
SEtI
Set Value of PID
Initial Current
4.00~20.00mA
12.00
Note:
[P213] Start/Stop Delay:
1. Delay Time of Feeder Starting: When there is a “DI.Start” pulse signal input, „DO. Scale Start&Stop Control‟ will
turn on to start the belt weigher, and after delaying this time, „DO. Feeder Start&Stop Control‟ will turn on to start the
feeder.
2. Delay Time of Scale Stopping: When there is a “DI.Stop” pulse signal input, „DO. Feeder Start&Stop Control‟ will
turn off to stop the feeder, and after delaying this time, „DO. Scale Start&Stop Control‟ will turn off to stop the belt
weigher.
