Supmeter BST100-B11 User Manual

38
6.3.3 Basic Control Parameters (CtrL)
No.
Sign
Parameter
Range
Default
Set
P200
SEtF
Flow Setpoint
0.00~5000.00t/h
([P107] Scale Unit = kg)
20.00
0.00~5000.00kg/h
([P107] Scale Unit = g)
P201
--P-
P Value
0.1~5000.0
A bigger P value indicates a higher-precision
feeding adjustment but a longer time for flow
to reach the target value [Flow Setpoint].
100.0
P202
--I-
I Value
0.1-9.9s
A smaller I value indicates a higher-frequency
feeding adjustment but a potential flow
over-adjustment.
0.5
P203
PIHI
PID Upper Limit
[P204]~20.00mA
Auto[PID]/Manual Control Current Upper
Limit
20.00
P204
PILo
PID Lower Limit
4.00~[P203]mA
Auto[PID]/Manual Control Current Lower
Limit
5.00
P205
rAtE
PID Control Ratio
1~500%
The 2nd&3rd Control Current=Control
Ratio×(The 1st Control Current-4.00)+4.00
[mA]
100%
P206
oVEr
Flow Positive
Deviation Limit
(0.5~100.0)%
10.0%
P207
Undr
Flow Negative
Deviation Limit
(0.5~100.0)%
10.0%
P208
CtrL
Feeding Control
Mode
0: Auto[PID]
1: Manual
2: Communication
1
P209
FLSt
Flow Set Mode
0: Internal/Communication
1: External AI: 4~20mA
0
