13
4.1.2 Model Wall-mounting Installation
Outline dimension
W×H×D [mm]
Mounting dimension
W×H [mm]
Mounting hole dimension
[mm]
202×305×90
169×271
Ф9
Outline dimension
Installation mode
www.zemicusa.info
