6.3.9 Communication Parameters (SErP)
No.
Sign
Parameter
Range
Default
Set
P700
-Adr
Communication Address
00~99
01
P701
P702
bPS1
bPS2
COM1 Baud Rate
COM2 Baud Rate
0: 1200bps
1: 2400bps
2: 4800bps
3: 9600bps
4: 19200bps
5: 115200bps
3
3
P703
P704
CHC1
CHC2
COM1 Parity Check
COM2 Parity Check
0: None
1: Even
2: Odd
0
0
P705
Con1
COM1 Communication
Mode
0: Host-slave Modbus ASCII
1: Continuous Sending ASCII
2: DP-Modicon (Profibus-DP; Data
Format: 4321)
3: DP-Siemens (Profibus-DP; Data
Format: 1234)
4: Print[A]
5: Print[B]
6: Host-slave Modbus RTU
7: Continuous Sending RTU
8: TCP
9: User1
0
P706
Con2
COM2 Communication
Mode
0: Host-slave Modbus ASCII
1: Continuous Sending ASCII
2: Unused
3: Unused
4: Print[A]
5: Print[B]
6: Host-slave Modbus RTU
7: Continuous Sending RTU
8: TCP
9: User1
0
P707
dAtF
Data Format
0: 4321
1: 3412
2: 1234
3: 2143
0
