7
Switch Signal Output Interface (DO)
4 Definable Normally Open Relay or Transistor Switch Outputs.
Capacity of Relay Switch: AC250V/DC24V, 1A.
Capacity of Transistor Switch: DC24V, 500mA.
Switch Signal Input Interface (DI)
3 Definable Normally Open Switch Inputs.
Digital Communication Interface (COM1/2)
COM1 Optional: RS232/RS485/RS422/Profibus-DP/CANBUS/Ethernet modules.
COM2: RS232.
Connectable: IPC/PLC, Remote Display&Operation Terminal, Serial Printer and Wireless
Module.
Power Supply Output: DC5V, 100mA.
Report Print
Weight Records per shift/day/month of a year can be queried and printed.
Outline Dimension
Model Panel-mounting: 160 × 84 × 188 mm (W×H×D).
Model Wall-mounting: 202 × 305 × 90 mm(W×H×D).
Cut Dimension
Model Panel-mounting: 151 × 76 mm(W×H).
Weight
Model Panel-mounting: Approx. 1.5kg.
Model Wall-mounting: Approx. 3.4kg.
Temperature and Humidity
Service Temperature: -25℃ to +40℃.
Storage Temperature: -30℃ to +60℃.
Relative Humidity: Max. 85%RH.
Protection Level
Model Panel-mounting: IP50.
Model Wall-mounting: IP65.
