SureTouch Refrigerated Liquid Dispensers • SureShot Technical Assistance Center: 1-888-777-9990 or 902-865-9602
14
Product Tanks and Lids
1. Remove the empty tank from the product compartment.
2. Remove the product delivery tube from the tank. Discard tube.
3. Rinse the tank and lid thoroughly with warm, clean water.
4. Wash in hot water (minimum 140 °F/60 °C) with a good quality cleaner. Wash
thoroughly to reach all corners and crevices. Wash the tank outlet spout area using a
small bottle brush.
If a dishwasher is available, the items may be cleaned on the full wash cycle.
5. Rinse well with warm, clean water.
6. Air dry thoroughly.
7. Sanitize the tank and lid using a sanitizing agent approved by your organization
according to its specifications.
8. Allow the tank and lid to drain completely. Do not rinse.
Valve Assembly
Note: Use caution not to dislodge any attached wires during cleaning.
Prior to taking the valve assembly apart, prepare containers of:
1. Warm, clean, soapy wash water.
2. Warm, clean rinse water.
3. Sanitizing agent approved by your organization according to its specifications.
IntelliShot (Portion Controlled) Dispensers
It is necessary to remove the valve from the dispenser and take the valve apart to clean.
Note: The diagrams show a three (3) product dispenser. The procedures apply to one
(1), two (2), and three (3) product models.
1. Turn the power to the dispenser OFF.
2. Unplug the dispenser.
3. Follow instructions to Remove an Empty Product Bag,
Bag-In-Box or Tank on page 7.
a. Tanks may be stored in a refrigerator until the valve
cleaning procedure is complete.
b. Bags and bag-in-box must be discarded. Dispense
amounts from a reloaded partial bag or bag-in-box will
be inaccurate.
4. Remove the catch tray and screen (if applicable) by lifting
it up and off.
5. Remove splash panel by removing the four (4) screws that
secure it in place. Carefully remove the splash panel.
6. Clean the splash panel.
a. Wash thoroughly.
If a dishwasher is available, it may be cleaned on the
full wash cycle.
b. Rinse well with warm, clean water.
c. Wipe dry with a soft cloth to prevent water spotting.
7. Remove the screw at the top of the metal valve insert.
Clean valve insert and screw and keep for reuse.
To Next Page
