FUEL AND LUBRICATION SYSTEM 4-15
• Position the diaphragm to the carburetor body properly.
• Align the lug on the carburetor with the intake pipe cutout A.
• Adjust the following items to the specification.
* Idling adjustment................................................... !2-10
* Throttle cable play................................................. !2-10
LUBRICATION SYSTEM
OIL PRESSURE
!2-21
OIL FILTER
!2-9
OIL SUMP FILTER
!3-57
OIL PUMP
!3-37
