Suzuki UY125 Service Manual

5-18 CHASSIS
FRONT WHEEL (UY125S)
#
REMOVAL
• Disconnect the speedometer cable 1.
• Remove the front axle nut 2.
• Raise the front wheel off the ground with a jack or wooden
block.
• Remove the front axle and front wheel.
%
1 Spacer
2 Bearing
3 Front axle spacer
4 Bearing
5 Brake disc
6 Speedometer gearbox
7 Front axle
A Front axle nut
B Brake disc bolt
ITEM N·m kgf-m
A 42 4.2
B 23 2.3
Do not operate the brake lever after front wheel
removal.
