ENGINE 3-49
• Apply SUZUKI SUPER GREASE “A” onto the shaft and gear
of the kick starter drive gear.
* 99000-25010: SUZUKI SUPER GREASE “A”
• Install the kick starter driven gear 4.
• Apply SUZUKI SUPER GREASE “A” to the oil seal lip.
* 99000-25010: SUZUKI SUPER GREASE “A”
• Install the kick starter shaft new oil seal with the special tool.
$ 09925-98221: Bearing installer
REDUCTION GEAR
DISASSEMBLY
• Remove the driveshaft 1.
• Remove the driveshaft oil seal with the special tool.
$ 09913-50121: Oil seal remover
#
INSPECTION
* Drive gear, idle gear and driveshaft damage or wear
* Improper tooth contact
* Shaft spline damage
Replace the removed oil seal with a new one.
