PERIODIC MAINTENANCE 2-5
• Remove the drain plug from the air cleaner box to allow any
water to drain out.
EXHAUST PIPE BOLT AND MUFFLER
MOUNTING NUT
• Tighten the exhaust pipe bolts 1 and muffler mounting bolts
2.
COOLING FAN FILTER
• Remove the cooling fan cover 1.
• Remove the holder 2 and cooling fan filter 3.
• Clean the fan filter in the same manner of the air cleaner ele-
ment.
• Reinstall the cleaned or new filter in the reverse order of
removal.
"
Tighten initially at 1 000 km (5 months) and every
8 000 km (40 months) thereafter.
Clean every 3 000 km.
Do not apply engine oil to the filter after cleaning it.
