3-52 ENGINE
• Install the engine mounting bushing using two steel tubes of
the appropriate size and a vise. Press the mounting bushing
into the crankcase holes. (!7-23)
LEFT CRANKCASE
BEARING/OIL SEAL REMOVAL
• Remove the bearing retainer 1.
• Remove the rear axle shaft bearing with the special tool.
$ 09921-20240: Bearing remover set (20 mm)
#
• Remove the rear axle shaft oil seal with the special tool.
$ 09913-50121: Oil seal remover
#
• Remove the idle shaft bearing 2 and driveshaft bearing 3
with the special tool.
$ 09921-20240: Bearing remover set 2 (15 mm)
3 (12 mm)
#
Replace the removed bearing with a new one.
Replace the removed oil seal with a new one.
Replace the removed bearing with a new one.
