6-14 ELECTRICAL SYSTEM
Step 4
1) Check the starter relay. (!6-20)
Is the starter relay OK?
Starter motor runs but does not crank the engine.
Step 1
1) Check the starter clutch.
Is the starter clutch OK?
STARTER MOTOR REMOVAL
• Disconnect the battery - lead wire.
• Remove the cooling fan duct. (!3-44)
• Remove the crankcase grommet No.1 and No.2. (!3-10)
• Disconnect the starter motor lead wire 1.
• Remove the starter motor 2.
YES Poor contact of the starter relay
NO Faulty starter relay
YES Faulty starter motor
NO Faulty starter clutch
