CHASSIS 5-15
REASSEMBLY AND INSTALLATION
Reassemble and install the front wheel and front brake in the
reverse order of removal and disassembly. Pay attension to the
following points:
WHEEL BEARING
• Apply SUZUKI SUPER GREASE “A” to the wheel bearings.
' 99000-25010: SUZUKI SUPER GREASE “A”
• Install the wheel bearings using the special tool.
$09924-84521: Bearing installer set
%
* First, install the left wheel bearing, and then install
the right wheel bearing.
* The sealed cover on the bearing must face out.
Clearance
