PERIODIC MAINTENANCE 2-3
LUBRICATION POINTS
Proper lubrication is important for smooth operation and long life of each working part of the motorcycle.
Major lubrication points are indicated below.
NOTE:
* Before lubricating each part, clean off any rusty spots and wipe off any grease, oil, dirt or grime.
* Lubricate exposed parts which are subject to rust, with a rust preventative spray whenever the motorcycle
has been operated under wet or rainy conditions.
Rear brake
lever holder
Speedometer
cable
Center stand pivot
and spring hook
Speedometer
gearbox
Side-stand pivot
and spring hook
Footrest pivot
Throttle cable
Front brake
lever holder
