ENGINE 3-21
REASSEMBLY
• Reassembly the cylinder head cover in the reverse order of
disassembly. Pay attention to the following points:
• Install the breather cover gasket 1.
#
• Tighten the breather cover bolts to the specified torque.
" Breater cover bolt: 10 N·m (1.0 kgf-m)
• Apply THREAD LOCK to the PAIR reed valve cover bolts and
tighten them.
% 99000-32050: THREAD LOCK “1342”
CYLINDER HEAD
#
DISASSEMBLY
• Remove the cam chain tensioner 1.
• Remove the camshaft retainer 2.
Replace the removed breather gasket with a new one.
Identify the position of each removed part. Organize
the parts in their respective groups (i.e., intake or
exhaust) so that they can be installed in their original
locations.
To Next Page
