HOW TO USE THIS MANUAL
TO LOCATE WHAT YOU ARE LOOKING FOR:
1. The text of this manual is divided into sections.
2. The section titles are listed in the GROUP INDEX.
3. Holding the manual as shown at the right will allow you to find
the first page of the section easily.
4. The contents are listed on the first page of each section to
help you find the item and page you need.
COMPONENT PARTS AND WORK TO BE DONE
Under the name of each system or unit, is its exploded view. Work instructions and other service information
such as the tightening torque, lubricating points and locking agent points, are provided.
Example: Front wheel
"
1 Spacer
2 Dust seal
3 Bearing
4 Front wheel spacer
5 Front wheel
6 Bearing
7 Front brake shoe
8 Dust seal
9
Speedometer drive
gear
0 Front brake camshaft
A Front brake panel
B
Speedometer driven
gear
C Front brake cam lever
D Front axle
A Front axle nut
B Spoke nipple
C
Front brake cam lever
bolt
ITEM N·m kgf-m
A 42 4.2
B 4.5 0.45
C 80.8
