Suzuki VL125 Service Manual

SERVICING INFORMATION 9-25
ITEM N
.
m kgf
.
m lb-ft
Oil plug 6 mm 6 0.6 4.3
8 mm 18 1.8 13.0
10 mm 15 1.5 11.0
14 mm 23 2.3 16.5
16 mm 35 3.5 25.5
Engine mounting bolt 79 7.9 57.0
Engine mounting bracket bolt 23 2.3 16.5
Frame mounting bolt/nut 8 mm 23 2.3 16.5
10 mm 50 5.0 36.0
Exhaust pipe clamp bolt 23 2.3 16.5
Muffler mounting bolt 23 2.3 16.5
Speed sensor rotor bolt 100 10.0 72.5
Spark plug 18 1.8 13.0
SECONDARY AND FINAL
ITEM N
.
m kgf
.
m lb-ft
Secondary drive bevel gear bearing retainer bolt 23 2.3 16.5
Secondary driven bevel gear bolt 23 2.3 16.5
Secondary driven bevel gear bearing stopper 105 10.5 76.0
Final gear case mounting nut 40 4.0 29.0
Final drive bevel gear coupling nut 100 10.0 72.5
Final drive bevel gear bearing stopper 110 11.0 79.5
Final gear case oil drain plug 23 2.3 16.5
Final gear case bolt 8 mm 23 2.3 16.5
10 mm 50 5.0 36.0
Final driven bevel gear bearing retainer screw 9 0.9 6.5

Suzuki VL125 Specifications

General

Displacement	124 cc
Ignition	Electronic ignition (CDI)
Starter	Electric
Transmission	5-speed constant mesh
Final Drive	Chain
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Swingarm, coil spring, oil damped
Rear Brake	Drum
Overall Length	2, 080 mm
Overall Width	760 mm
Ground Clearance	150 mm
Fuel System	Carburetor
Front Brake	Single disc
Front Tire	90/90-18
Seat Height	735mm
