Swann AMI Codes-II - Page 100

98 A-96.250.571 / 050517
AMI Codes-II
Default Values
pH: Alarm high: .................................................................. 14.00 pH
pH: Alarm low:...................................................................... 0.00 pH
pH: Hysteresis: .................................................................... 0.10 pH
pH: Delay: ................................................................................5 Sec
Sample Flow: Flow Alarm: .......................................................... yes
Sample Flow: Alarm High: ....................................................500 B/s
Sample Flow: Alarm Low: .........................................................5 B/s
Sample Temp.: Alarm High: .....................................................55 °C
Sample Temp.: Alarm Low: ........................................................5 °C
Case temp. high:......................................................................65 °C
Case temp. low: .........................................................................0 °C
Relay 1and 2 Function: ......................................................................... Limit upper
Parameter: .................................................................................DIS.
Setpoint:.............................................................................5.00 ppm
Hysteresis: .........................................................................0.10 ppm
Delay:.....................................................................................30 Sec
If Function = Control upw. or dnw:
Parameter: ..................................................................................DIS
Settings: Actuator: ...........................................................Frequency
Settings: Pulse Frequency: ............................................ 120/min.
Settings: Control Parameters: Setpoint: .........................5.00 ppm
Settings: Control Parameters: P-band:...........................0.10 ppm
Parameter: ................................................................................... pH
Settings: Actuator: ...........................................................Frequency
Settings: Pulse Frequency: ............................................ 120/min.
Settings: Control Parameters: Setpoint: ........................... 7.00 pH
Settings: Control Parameters: P-band:............................. 0.10 pH
Parameter: .................................................................. Temperature
Settings: Actuator: ...........................................................Frequency
Settings: Pulse Frequency: ............................................ 120/min.
Settings: Control Parameters: Setpoint: ...............................30 °C
Settings: Control Parameters: P-band:...................................1 °C
Parameter: ..................................................................Sample Flow
Settings: Actuator: ...........................................................Frequency
Settings: Pulse Frequency: ............................................ 120/min.
Settings: Control Parameters: Setpoint: ........................... 200 B/s
Settings: Control Parameters: P-band:............................... 20 B/s
Common settings
Settings: Control Parameters: Reset time: ...........................0 Sec
Settings: Control Parameters: Derivative Time: .................
..0 Sec
Settings: Control Parameters: Control Timeout:................... 0 Min
