68 A-96.250.571 / 050517
AMI Codes-II
Troubleshooting
E011 Temp. shorted
– check wiring of temperature sensor, see
Connection Diagram, p. 26
– check temperature sensor
E012 Temp. disconnected
– check wiring of temperature sensor, see
Connection Diagram, p. 26
– check temperature sensor
E013 Case Temp. high
– check case/environment temperature
– check programmed value in menu
5.3.1.5, p. 88
E014 Case Temp. low
– check case/environment temperature
– check programmed value in menu
5.3.1.6, p. 88
E017 Control Timeout
– check control device or programming in
Installation, Relay contact, Relay 1/2
5.3.2 and 5.3.3, p. 88
E018 Reagent Pump
– shut off power
– check wiring, see Connection Diagram,
p. 26
E019 Photometer not con-
nected
– shut off power
– check wiring of photometer, see
Connection Diagram, p. 26
E020 Photometer dirty
– check process,
– clean photometer, see Cleaning the
Photometer, p. 54
E021 DIS. invalid
– This error appears after start-up and will
disappear after the first valid
measurement is finished.
E022 Reagent empty
– refill reagents, see Refill or replace
Reagents, p. 43
E023 Cleaning solution
– refill cleaning solution
E024 Input active
– See If Fault Yes is programmed in Menu
5.3.4, p. 93
E026 IC LM75
– call service
E028 Signal output open
– check wiring on signal outputs 1 and 2
Error Description Corrective action
