2.3. Instrument Overview
A
B
C
D
E
F
G
H
I
Panel
Transmitter
pH/Redox electrode
Temperature sensor
Calibration solution pH 7
Calibration solution pH9
Constant head
Reference electrode
Flow regulating valve
J
K
L
M
N
O
P
Q
Grab sample valve
Grab sample outlet
Trides sensor
Filter
Sample outlet
Sample inlet
Hall-effect sensor
Flow cell block
