Swann AMI Trides - Cleaning of Reference Electrode

46 A-96.250.111 / 211019
AMI Trides
Maintenance
6.4. Cleaning of Reference Electrode
1 Close the flow regulating vale.
2 Loosen the union screw [B]
3 Pull the reference electrode out.
4 Wipe sensor tip cautiously with a soft tissue. If necessary use
alcohol to remove oily deposits.
Do not use any acid!
5 Push the reference electrode through the union screw into the
flow cell as far as it will go.
6 Tighten the union screw.
A
B
Reference electrode
Union screw
E
F
Washer
O-Ring
C
D
B
A
