5.3. Software Structure
Menu 1 Messages
Reveals pending errors as well as an event history
(time and state of events that have occurred at an
earlier point of time).
It contains user relevant data.
Menu 2 Diagnostics
Provides user relevant instrument and sample data.
Menu 3 Maintenance
For instrument calibration, relay and signal output
simulation, and to set the instrument time.
It is used by the service personnel.
Menu 4 Operation
User relevant parameters that might need to be
modified during daily routine. Normally password
protected and used by the process-operator.
Subset of menu 5 - Installation, but process-related.
Menu 5 Installation
For initial instrument set up by SWAN authorized
person, to set all instrument parameters. Can be
protected by means of password.
1
Messages
Operation
Maintenance
Diagnostics
Main Menu
Installation
1.1
Pending Errors
Messages
Message List
2.1
Interface
I/O State
Sample
Identification
Sensors
Diagnostics
3.1
Calibration
Maintenance
Set Time 23.09.06 16:30:00
Simulation
4.1
Logger
Relay Contacts
Sensors
Operation
5.1
Interface
Miscellaneous
Relay Contacts
Sensors
Signal Outputs
Installation
To Next Page
