AMI Trides
Program List and Explanations
A-96.250.111 / 211019 79
When the relays are used as upper or lower limit switches, program
the following:
5.3.2.20 Parameter: choose one of the following process values
DIS.
pH/Redox
Temperature
Sample Flow
5.3.2.300 Setpoint: If the measured value rises above respectively falls below
the set-point, the relay is activated.
5.3.2.400 Hysteresis: within the hysteresis range, the relay does not switch.
This prevents damage of relay contacts when the measured value
fluctuates around the alarm value.
5.3.2.50 Delay: Duration, the activation of the alarm relay is retarded after
the measuring value has risen above/fallen below the programmed
alarm.
Range. 0–600 Sec
5.3.2.1 Function = Limit upper/lower:
Parameter Range
DIS 0.00–10 ppm
pH/Redox -3.00 to +15.00 pH
Temperature -30 °C to +120 °C
Sample Flow 0–600 rpm
Parameter Range
DIS 0.00–10 ppm
pH/Redox 0–2 pH
Temperature 0–120 °C
Sample Flow 0–600 rpm
