88 A-96.250.111 / 211019
AMI Trides
Default Values
Sample Flow:
Flow Alarm .................................................................................. yes
Alarm high:...........................................................................500 rpm
Alarm low: ............................................................................290 rpm
Delay............................................................................................ 5 s
Sample Temp:
Alarm High: ..............................................................................55 °C
Alarm Low:.................................................................................5 °C
Case temp. high:......................................................................65 °C
Case temp. low: .........................................................................0 °C
Relay 1/2 Function: .......................................................................... limit upper
Parameter: .................................................................................DIS.
Setpoint:.............................................................................5.00 ppm
Hysteresis: .........................................................................0.10 ppm
Delay:......................................................................................... 30 s
If Function = Control upw. or dnw:
Parameter: .................................................................................DIS.
Settings: Actuator: ...........................................................Frequency
Settings: Pulse Frequency:................................................. 120/min
Settings: Control Parameters: Setpoint: ............................5.00 ppm
Settings: Control Parameters: P-band: ..............................0.10 ppm
Settings: Control Parameters: Reset time: .................................. 0 s
Settings: Control Parameters: Derivative Time:........................... 0 s
Settings: Control Parameters: Control Timeout: ...................... 0 min
Settings: Act. Time prop.: Cycle time: ....................................... 60 s
Settings: Act. Time prop.: Response time: ................................ 10 s
Settings: Act. Motor valve: Run time: ........................................ 60 s
Settings: Act. Motor valve: Neutral zone: ....................................5%
If Function = Timer:
Mode: Interval: ......................................................................... 1 min
Mode: daily/weekly: ......................................Starting time: 00.00.00
Run time: ................................................................................... 10 s
Delay:........................................................................................... 5 s
Signal output:............................................................................ cont.
Output/Control: ......................................................................... cont.
Input: Active ............................................................................when closed
Signal Outputs ........................................................................... hold
Output/Control .............................................................................. off
Fault..............................................................................................no
Delay.......................................................................................... 10 s
