8.3.4 Downspeed Control of Fan Speed to Min. Set
Point, Airflow/pressure
Regulation of the supply airflow to a lower flow rate is the
last step in the regulation sequence on increasing heat-
ing load for ERS regulation or supply air regulation. The
extract air fan cannot be selected alone; only the supply
air fan or both the supply air and extract air fans can be
selected.
See Section 8.2 as well.
An adjustable temperature decrease allows a lower supply
air temperature setpoint, before down regulation begins.
This neutral zone can be set on line NZ SA DOWN REGU-
LATION in the appropriate menu.
Settings:
Value Setting Factory
range settings
Function Inactive/SA/SA+EA Active
Neutral zone 0.0-10.0 °C 0.0 °C
8.3.5 To adjust the flow of the slave fan
It is possible to preset the set point of the slave fan to
provide a higher or lower airflow than the current airflow
of the controlling fan.
The deviation from the airflow of the controlling fan can
be preset by entering a COP. A cooling COP of 0.5 denotes
that the airflow of the slave will be 50% of the master
fan’s airflow.
Settings:
Value Setting Factory
range settings
Cooling COP 0.5-2,0 1,0
8.4 To Activate the GOLD SD Filter Monitor-
ing Function
The filter monitoring function must be activated for the
filters that are to be monitored.
Settings:
Value Setting Factory
range settings
Standard filter Inactive/SA/EA Inactive
SA+EA
Prefilter Inactive/SA/EA Inactive
SA+EA
* AIRFLOW/PRESSURE *
