INSTALLATION
INSTALLATION
14 COMMUNICATION
Provision for communication and supervision is inte-
grated as standard into the GOLD. The unit is ready
to be connected via EIA-232, EIA-485 and Ethernet.
For particulars of connecting and wiring the air
handling unit, see Section 19.5 Wiring to Terminals,
Sizes 04-80.
Communication can also be established via Ether-
net without software other than an ordinary web
browser such as Internet Explorer.
Further information about interfaces, proto-
col and configuration is available at www.
swegon.com.
14.1 EIA-232
Protocol and settings for EIA-232 is specified.
Settings:
Value Setting range
Modbus RTU Address, speed, parity, stop bits
GSM-modem
Analogue modem
14.2 EIA-485
Protocol and settings for EIA-485 is specified.
Settings:
Value Setting range
Modbus RTU Address, speed, parity, stop bits
Metasys N2 OPEN
Lon Works/TREND
Exolinc
14.3 Ethernet
Protocol and settings for Ethernet is specified.
Settings:
Value Setting range
Ethernet MAC ID
DHCP SERVER
(active or inactive)
IP ADDRESS
(static or dynamic)
SUBNETM.
GATEWAY
DNS-SERVER
MODBUS TCP CLIENT
(IP address and mesh)
BACNet IP
(active or inactive, Device ID,
Port no.)
SERVICE LEV.
COMMUNICATION
*COMMUNICATION*
EIA-232
EIA-485
ETHERNET
*SERVICE LEV.*
CODE:0000
15 SERVICE LEVEL
A code and special training are required for access to this
menu group.
