8.11 All Year Comfort
The All Year Comfort function controls the supply flow
temperature to comfort modules, chilled beams, perimeter
climate systems, etc. via regulating valves. Two strap-on
temperature sensors fitted either to the water pipe or the
regulating valve are used for measuring the water tem-
perature.
The function requires the electrical equipment cubicle
accessory (TBLZ-1-59-a-b-cc) for controlling the supply
flow water temperature. The function selector switch of
the electrical equipment cubicle must be set to position 7.
All Year Comfort has functions for outdoor compensation,
room compensation, night compensation, dew point com-
pensation and for controlling pump and valve exercising.
For further information, see the Guide to the All Year
Comfort Function.
Settings:
Value Setting Factory
range settings
All Year Comfort Inactive Inactive
Cooling
Heating
Cool.+Heat.
Heating water temperature (°C) 10-80°C 30
Cooling water temperature (°C) 5-30°C 14
Outdoor comp. Heat. water Active Inactive
Inactive
Outdoor temp. (X1) (°C) -40 - 40°C -20
Heating water (Y1)(°C) 10 - 80°C 40
Outdoor temp. (X2)(°C) -40 - 40°C 5
Heating water (Y2)(°C) 10 - 80°C 30
Outdoor temp. (X3)(°C) -40 - 40°C 15
Heating water (Y3)(°C) 10 - 80°C 20
Outdoor comp., Cool. water Active Inactive
Inactive
Outdoor temp. (X1) (°C) -40 - 40°C 10
Cooling water (Y1)(°C) 5 - 30°C 22
Outdoor temp. (X2)(°C) -40 - 40°C 20
Cooling water (Y2)(°C) 5 - 30°C 18
Outdoor temp. (X3)(°C) -40 - 40°C 25
Cooling water (Y3)(°C) 5 - 30°C 14
Room comp., Heating water Active Inactive
Inactive
Room temperature (°C) 0 - 40°C 21
P-band (°C) 1 - 10°C 5
Night blocking Active Active
Inactive
Room comp., Cooling water Active Inactive
Inactive
Room temperature (°C) 0 - 40°C 21
P-band(°C) 1 - 10°C 5
Night blocking Active Active
Inactive
Night comp., heating water Active Inactive
Inactive
Temp. comp. (°C) -10 - +10°C -2
Night comp., Cooling water Active Inactive
Inactive
Temp. comp. (°C) -10-+10 °C 2
*ALL YEAR COMFORT*
FUNCTION ON/OFF
SETTINGS
Night comp. Inactive Inactive
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
Monday-Friday
Monday-Sunday
Saturday-Sunday
Channel 1-2
Pump op., Heating water
Outdoor temp. Start (°C) -40 - 40°C 15
Pump op., Heating water
Outdoor temp. Stop (°C) -40 - 40°C 18
Pump op., Cooling water
Outdoor temp. Start (°C) -40 - 40°C -20
Pump op., Cooling water
Outdoor temp. Stop (°C) -40 - 40°C -25
Pump/valve
Pump alarm, heating water Inactive Inactive
Normally closed
Normally open
Contactor
Valve, heating water Active Inactive
Inactive
Pump alarm, cooling water Inactive Inactive
Normally closed
Normally open
Contactor
Valve, cooling water Active Inactive
Inactive
Exercising, heating water Inactive Inactive
Pump
Pump+Valve
Valve
Exercising period, (min) 1-60 min 3
Interval (h) 1-168 h 24
Exercising, Cooling water Inactive Inactive
Pump
Pump+Valve
Valve
Exercising period, (min) 1-60 min 3
Interval (h) 1-168 h 24
Dew point comp. Active Inactive
Inactive
Neutral zone(°C) 0-5°C 2
Comp. flow (%) 0-30% 10
