Function Factory preset value Adjusted value
Temperature
8)
Temp. regulation function X ERS 1 ERS 2 SA EA ERS 1 ERS 2 SA EA
Differential SA/EA (°C) 3.0
Step 2
Breakpoint (°C) 22.0
X1 15.0
Y1 20.0
X2 20.0
Y2 18.0
X3 22.0
Y3 14.0
Setpoint (°C) 21.5 21.5
Min SA temp (°C) 15.0
Temperature control Xzone 8)
Temp control function ERS 1 ERS 2 X SA EA ERS 1 ERS 2 SA EA
Difference TL/FL (°C) 3,0
Steps 2
Breakpoint (°C) 22,0
X1 15,0
Y1 20,0
X2 20,0
Y2 18,0
X3 22,0
Y3 14,0
Setpoint (°C) 21,5 21,5
Min. SA temp. (°C) 15,0
Max. SA temp. (°C) 28,0
Max SA temp (°C) 28.0
Outdoor temp. compensation
8)
X Inactive Active Inactive Active
Temperature
Winter comp. Y1 (°C) 3.0
End point, winter X1 (°C) -20.0
Start point winter X2 (°C) 10.0
Start point, summer X3 (°C) 25.0
End point, summer X4 (°C) 40.0
Summer comp. Y2 (°C) 2.0
Summer night cooling
8)
X Inactive Active Inactive Active
EA temp. start (°C) 22.0
EA temp. stop (°C) 16.0
Outd. air temp. stop (°C) 10.0
SA Setpoint (°C) 10.0
Op. period start (hh:mm) 23:00
Op. period stop (hh:mm) 06:00
Intermittent nighttime heating
8)
X Inactive Active Inactive Active
SA/Room start (°C) 16.0
EA/Room stop (°C) 18.0
SA Night setpoint (°C) 28.0
SA flow (m²/s / Pa)
1)
EA flow (m²/s / Pa) 0.0
Control output
X IQnomic IQnomic+ IQnomic IQnomic+
Damper output =0
