Sym Citycom 300i Service Manual

13. Body Cover
13-7
Inner Box
Remove
Remove 1 screw on the fuse box stay and . 1
screw on the reserve tank stay.
Remove the dc power outlet connect.
Remove main switch cap bolt then remove main
switch cap.
Loosen 2 screws from the front spoiler.
Open inner box lid.
Remove 1 screw from the inner box in side.
Remove 1 screw from reserve tank lid.
Remove 1 bolt from luggage hook then remove
luggage hook.
bolt
2 screws
power outlet
connect
reserve tank
inner box
lid
luggage
hook
To this chapter contents

Sym Citycom 300i Specifications

General

Engine Type	4-stroke, Single Cylinder
Displacement	278.3 cc
Fuel System	Electronic Fuel Injection
Cooling System	Liquid Cooled
Front Suspension	Telescopic Fork
Rear Suspension	Dual Shock Absorbers
Front Tire	110/70-16
Rear Tire	140/70-16
Seat Height	800 mm
Transmission	CVT
Front Brake	Disc
Rear Brake	Disc
Fuel Capacity	10 liters
