Sym Citycom 300i Service Manual

8
. V-Belt Driving System
8-3
Left Crankcase Cover
Left crankcase cover removal
Loosen 4 bolts from left side crank out cover &
remove it.
Remove left crankcase cover. (9 bolts)
Remove 2 dowel pin and gasket.
Left crankcase cover install
Install left crankcase cover in the reverse
procedures of removal.
To this chapter contents
8 bolts
Left cover plate
Bearing setting plate
Drive shaft holder bearing

Sym Citycom 300i Specifications

General

Engine Type	4-stroke, Single Cylinder
Displacement	278.3 cc
Fuel System	Electronic Fuel Injection
Cooling System	Liquid Cooled
Front Suspension	Telescopic Fork
Rear Suspension	Dual Shock Absorbers
Front Tire	110/70-16
Rear Tire	140/70-16
Seat Height	800 mm
Transmission	CVT
Front Brake	Disc
Rear Brake	Disc
Fuel Capacity	10 liters
