Sym Citycom 300i Service Manual

Contents
Page Content Index
1-1 ~ 1-16
General Information
1
2-1 ~ 2-17
Maintenance Information
2
3-1 ~ 3-8
Lubrication System
3
4-1 ~ 4-60
Fuel Injection System
4
5-1 ~ 5-11
Engine Removal
5
6-1 ~ 6-16
Cylinder Head/ Valve
6
7-1 ~ 7-8
Cylinder/ Piston
7
8-1 ~ 8-14
“V” Type Belt Driving System/ Kick-Starter
8
9-1 ~ 9-8
Final Drive Mechanism
9
10-1 ~ 10-10
Alternator
10
11-1 ~ 11-8
Crankshaft/ Crankcase
11
12-1 ~ 12-14
Cooling System
12
13-1 ~ 13-16
Body Cover
13
14-1 ~ 14-12
Brake System
14
15-1 ~ 15-10
Steering/ Front Wheel/ Front Cushion
15
16-1 ~ 16-6
Rear Wheel/ Rear Fork/ Rear Cushion
16
17-1 ~ 17-23
Electrical Equipment
17
18-1 ~ 18-7
Emission Control System
18
19-1
Electrical Diagram
19
Homepage

Sym Citycom 300i Specifications

General

Engine Type	4-stroke, Single Cylinder
Displacement	278.3 cc
Fuel System	Electronic Fuel Injection
Cooling System	Liquid Cooled
Front Suspension	Telescopic Fork
Rear Suspension	Dual Shock Absorbers
Front Tire	110/70-16
Rear Tire	140/70-16
Seat Height	800 mm
Transmission	CVT
Front Brake	Disc
Rear Brake	Disc
Fuel Capacity	10 liters
