Symbols and Marks
Symbols and marks are used in this manual to indicate what and where the special service are needed,
in case supplemental information is needed for these symbols and marks, explanations will be added to
the text instead of using the symbols or marks only.
Warning
Means that serious injury or even death may result if procedures are not
followed.
Caution
Engine oil
Limits to use SAE 10W-40 API SL class oil. Warranty will not cover the
damage that caused by not apply with the limited engine oil.
(Recommended oil: LIQUI MOLY Racing 4T 10W-40 oil)
Grease LIQUI MOLY LM50is recommended.
Gear oil
LIQUI MOLY gear oil serials are recommended. (GL4/5 GEAR OIL
SAE 75W-90)
Locking sealant
Apply sealant, medium strength sealant should be used unless otherwise
specified. Recommended LIQUI MOLY
Oil seal Apply with lubricant. .
Renew
Replace with a new part before installation.
Brake fluid
Use LIQUI MOLY brake fluid DOT3.
Special tools
Special tools
Correct
Meaning correct installation.
Wrong
Meaning wrong installation.
Indication Indication of components.
Directions
Indicates position and operation directions
Components assembly directions each other.
Indicates where the bolt installation direction, --- means that bolt cross
through the component (invisibility).
