Sym Mio 100 Service Manual

12. Body Cover
12-13
Body Cover
Removal
Remove the right and left side covers (2 screws).
Remove the luggage box (4 bolts).
Remove the rear carrier (2 bolts & 2 nuts).
Remove the body cover two side screws. (1 screw
on each side)
Remove the body cover rear side screws. (1 screw
on each side)
Remove seat lock cable.
Remove body cover.
Installation
Install according to the reverse procedure of
removal.
1 screw on each side
Seat lock cable
1 screw on each side
To this chapter contents

Sym Mio 100 Specifications

General

Engine Type	4-stroke, Single Cylinder
Starting System	Electric & Kick
Transmission	CVT
Fuel System	Carburetor
Front Brake	Disc
Rear Brake	Drum
Tires Front	90/90-10
Tires Rear	90/90-10
Length	1760 mm
Height	1070 mm
Wheelbase	1230 mm
Fuel Tank Capacity	5.2 L
