Sym Mio 100 Service Manual

4. Fuel System
4-1
Mechanism Illustration ......................4-1
Operational Precautions....................4-2
Trouble Diagnosis..............................4-3
Carburetor...........................................4-4
Idle Speed Adjustment ...................... 4-8
Fuel Tank ............................................ 4-9
Air Cleaner.......................................... 4-11
Mechanism Illustration
Fuel tank cap
Fuel vapor separator
Fuel unit
Fuel tank
Vacuum hose
Vacuum type fuel coke
Carburetor
Fuel hose
Fuel drain screw
Mixture adjustment screw
Throttle valve stopper screw
4
Home page
Contents

Sym Mio 100 Specifications

General

Engine Type	4-stroke, Single Cylinder
Starting System	Electric & Kick
Transmission	CVT
Fuel System	Carburetor
Front Brake	Disc
Rear Brake	Drum
Tires Front	90/90-10
Tires Rear	90/90-10
Length	1760 mm
Height	1070 mm
Wheelbase	1230 mm
Fuel Tank Capacity	5.2 L
