13. Brake
13-1
Mechanism Diagram-Front Disc Brake
System ················································· 13-1
Mechanism Diagram-Front Drum Brake
System ················································· 13-2
Mechanism Diagram-Rear Drum Brake
System ················································· 13-3
Operational Precautions····················· 13-4
Trouble Diagnosis······························· 13-5
Hydraulic Brake System Inspection ·· 13-6
Brake Fluid Replacement / Air-Bleed · 13-7
Brake Caliper········································ 13-8
Brake Disc ············································ 13-9
Brake Master Cylinder························· 13-9
Drum Brake System····························· 13-12
Brake Lining ········································· 13-12
Brake Panel ·········································· 13-13
Mechanism Diagram-Front Disc Brake System
13
5.0~7.0kgf-m
4.0~4.5kgf-m
0.8~1.0kgf-m
3.3~3.7kgf-m
2.8~3.2kgf-m
