Mechanism Illustrations
HU05U / HU10U / HU10W
Exhaust muffler
Home page
Contents
Air cleaner
Fuel tank cap
Start / headlight switch
Battery / Fuse /
C.D.I. unit
Front brake lever
Rear brake lever
Back mirror
Luggage box
Luggage box lock
Helmet hook
Winker / Horn /
Hazard or
Seat open switch
Front winker
Headlight
Tail light
Main switch
Oil gauge
Fuel tank
Rear winker
