8. Cylinder / Piston
8-1
Mechanism Diagram ............................8-1 Piston Removal....................................8-4
Precautions in Operation ....................8-2 Piston Ring Installation.......................8-6
Troubleshooting...................................8-2 Piston Installation................................8-7
Cylinder Removal.................................8-3 Cylinder Installation ............................8-7
Mechanism Diagram
