9. V-Belt Drive System
9-1
Mechanism Diagram ............................9-1 Drive Belt............................................9-5
Precautions in Operation ....................9-2 Drive face............................................9-6
Troubleshooting...................................9-2 Clutch outer / Driven pulley ..............9-10
Left Crankcase Cover ..........................9-3
Mechanism Diagram
5.0~6.0 kgf-m
5.0~6.0 kgf-m
3.5~4.5 kgf-m
