6. Engine Removal
6-11
Remove the left rear cushion lower bolt.
Remove the engine hanger lock bolts from the
frame side.
Remove the engine and hanger.
Engine Hanger
Removal
Remove the engine hanger bolts from the engine
side.
Check if the engine hanger rubber bush is
damaged or not.
Replace it if necessary.
Installation
Install the engine hanger onto the engine and
make sure the locknut and bolt are locked
properly.
Torque value : 4.0~5.0kgf-m
Frame side bolt
Bolt
Engine side bolt
