18. Electrical System
18-1
Mechanism Diagram·························· 18-1
Precautions in Operation·················· 18-2
Troubleshooting ································ 18-3
Battery ················································ 18-4
Fuse ···················································· 18-5
Charging System ······························· 18-6
Ignition System·································· 18-9
Starting System ································· 18-10
Meter ··················································· 18-12
Light / Bulb ········································· 18-13
Switch / Horn······································ 18-18
Fuel Unit ············································· 18-20
Thermo Switch ··································· 18-21
Thermo Unit········································ 18-22
Thermo Guage ··································· 18-22
Mechanism Diagram
Homepage
Contents
18
Winker rela
y
Spark plug
AC. generator
Fuse box
Battery
Ignition coil
Main switch
Reg. Rec.
Starter relay
Fuel pump / fuel unit
Horn
High beam/winker/
Horn switch
Headlights relay (high beam)
Starter/headlight/hazard
switch
ECT sensor
Headlights relay (Low beam)
Thermo switch
DC solenoid
ECU
Fuel pump relay
