18. Electrical System
18-12
Meter
Removal
Remove the back mirror and front cover.
Remove the meter locknuts.
Disconnect the wire couplers.
Disconnect the speedometer cable and
remove the meter.
Disassemble the meter from the upper cover
(4 screws).
Installation
Install in the reverse order of removal.
4 screws
4 screws
Wire couplers
Speedometer cable
