16. Steering / Front Wheel / Front Cushion
16-3
Steering Handlebar
Removal
Remove the front handle cover. (Screw ×4)
Remove the rear handle cover. (Screw ×3)
Remove the right switch assembly by loosening
two screws.
Remove the acceleration cable and take off the
handlebar.
Loosen the lock bolt for the master cylinder of the
front brake.
Remove the master cylinder of the front brake.
Screw×4
Screw×1
Bolt×2
Screw×2
