Floor Panel
Removal
Remove the floor panel bolts on the upper
side.
Remove the floor panel bolts on the left / right
side.
Remove the floor panel.
Installation
Install in the reverse order of removal.
Under Cover
Removal
Remove the under cover bolts.
Remove the under cover.
Installation
Install in the reverse order of removal.
4 bolts
4 bolts
2 bolts
