17. Muffler / Rear Wheel / Rear Cushion
17-6
Remove an upper bolt from the shock absorber
(bolt x 1).
Remove the rear shock absorber.
Installation
In reverse order of removal.
Caution
Torque Value
Absorbing bolt: 2.4 ~ 3.0 kgf-m
Lock nut: 3.5 ~ 4.5 kgf-m
The shock absorber must be replaced as a
unit. Never disassemble the shock absorber
as that would damage the structure.
