Sym X'PRO RV125 User Manual

18. Electrical System
18-5
Fuse
Fuse circuit
To this chapter contents
Main switch
Battery
Fuse 10A
(Main switch)
Fuse15A
Fuse15A
(Headlight)
Fuse 15A
Fuel pump relay
Ignition coil
Meter
Horn
Starter switch
Fan
ECU
(Charge)
Fuse 20A
Regulator rectifier
AC generator
Headlight relay
(Low beam)
Fuse15A
R
R Y
R/W
R/Y
R
B
W/G
L
R Red
B Black
Y Yellow
W White
L Blue
R/W Red / White
W/G White / Green
R/Y Red / Yellow
B/O Black / Orange
Headlight relay
(High beam)
Fuel pump
Fuel injector
B/O
