Symbol LS9203 - Technical Specifications

Maintenance & Technical Specifications 3 - 3
Technical Specifications
Table 3-2 Technical Specifications
Item Description
Physical Characteristics
Dimensions:
without stand:
Height
Width
Depth
with stand:
Height
Width
Depth
5.51 in. (14 cm)
3.49 in. (8.8 cm)
2.96 in. (7.5 cm)
6.15 in. (15.62 cm)
3.87 in. (9.83 cm)
3.95 in. (10.03 cm)
Weight Scanner only: 9.9 oz/282 g
With stand: 12.2 oz/379 g
Power Source Power drawn from host or external power supply; depends on host type.
Voltage 5.0 VDC ± 10%
Nominal Current 275 mA
Power 2 watts
Mounting Options Fixed-mount stand
Color Twilight Black
Performance Characteristics
Light Source
650nm visible laser diode
Yaw Tolerance (Typical)
Note 1
Omnidirectional: ± 50°
Pitch Tolerance (Typical)
Note 1
Omnidirectional: ± 50°
Roll Tolerance (Typical)
Note 1
Omnidirectional: 0 to 360°
Print Contrast 25% minimum reflective difference
Scan Patterns Omnidirectional: 20 interlocking lines
Scan Rate Omnidirectional: 1500 scans/second
Depth of Field 0 to 8.5 in./0 to 21.6 cm @ 13 mil (100% UPC/EAN)
1
Refers to 100% UPC bar code (80% contrast) located 4 in./10 cm from the scanner nose.
