RS-232 6 - 3
RS-232 Default Parameters
Table 6-1 lists the defaults for RS-232 host parameters. To change any option, scan the appropriate bar code(s)
provided in the Parameter Descriptions section beginning on page 6-4.
NOTE See Appendix A, Standard Default Parameters for all user preferences, hosts, symbologies, and
miscellaneous default parameters.
Table 6-1
RS-232 Host Default Table
Parameter Default Page Number
RS-232 Host Parameters
RS-232 Host Types
Standard
1
6-6
Baud Rate 9600
6-10
Parity None
6-14
Check Receive Errors Enable
6-17
Hardware Handshaking None
6-18
Software Handshaking None
6-21
Host Serial Response Time-out 2 Sec
6-24
RTS Line State Low RTS
6-27
Stop Bit Select 1
6-28
Data Bits 8-Bit
6-29
Beep on <BEL> Disable
6-30
Intercharacter Delay 0 msec
6-31
Nixdorf Beep/LED Option Normal Operation
6-34
Ignore Unknown Characters Send Bar Codes
6-36
1
User selection is required to configure this interface and this is the most common selection.
