Taie FU series - 3 FY Series; 4 Terminal Arrangement; FY400; FU48 Terminals ( 48 Mm X 48 Mm, DIN 1;16 )

11
4. Terminal arrangement
4.1 FY400 / FU48 Terminals ( 48mm x 48mm , DIN 1/16 )
AC 85~265V
DC 15 ~50V(Option)
A.Power Supply
Relay SSR mA,V
OUT1
G1
K1
G2
K2
OUT1
(1ΦZero Cross
Control)
Relay SSR mA,V
OUT2
2
3
CLOSE
OPEN
COM
OUT1
(Proportional Motor
Valve Control)
B.Control Output
mA,V RTD
TC,mV
C.Input
2
3
AL 1
11
12
AL 1
13
14
AL 2
D.Alarm
TRS
E.Transmission
RS232
F.Communication
11
12
13
RD
SD
SG
RS485
11
12
Dx-
Dx+
TTL
11
12
13
RD
SD
SG
(Option)
(Use OUT1 & OUT2)
(Proportional Motor
Valve Control)
H.CT Input
CT
11
12
