56
18.5 3
ψ
Phase angle control (B
y DIODE/SCR module)
z
A
vailable
Models
：
FY900 / PFY900
z
OUT1:
3
ψ
SCR phase angle control
z
Parameter
setting
：
OUTY=5
CLO1=0
，
CHO1=4500 only if use for resistance load
CLO1=0
，
CHO1=4000 if use for inductor load
CONTROLLER
Short
K 1
G 1
K 2
G 2
K 3
G 3
T
S
R
FA
ST
FUSE
U
V
DIODE/SCR
Module
W
K 2
G 2
K 3
PROT
G 3
G 1
3
φ
LOAD
K 1
57
59
